| Brand Name: | Purple Horn |
| Model Number: | TE262302 |
| MOQ: | 1pcs |
| Price: | Negotiable |
| Delivery Time: | 3-5Working Days After Payment |
| Payment Terms: | L/C, T/T, Western Union, |
Home Using Fixed 4G Cellphone Signal Repeater/4G Smart Phone Signal Booster
Brief Description:
2600MHz Pico-Repeater is intended to strengthen the signal of 2600MHz mobile phone in the buildings. Ideal for use in areas where the 2600MHz signal is weak to cause Call dropout or Cant connection. The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator).
Features:
Applicable place:
It can be applied in Building rooms there have weak signal of mobile.
3G2600 MHz(LTE) Full Band Signal Booster Model TE-4G2600MHz70dB
| Frequency Range | Uplink:2500-2560MHz; Downlink:2620-2690MHz; |
| Gain (dB) | Uplink Gp: ≥65dB; |
| Downlink Gp: ≥70dB; | |
| Output Power(dBm) | ≥23 dBm; |
| Pass band ripple | ≤5dB |
| Guard band rejection | (BW-60dB)≤42 MHz; |
| (BW-70dB)≤45 MHz; | |
| I/O impedance | 50Ω/N Connector |
| I/O return loss | ≤-8dB |
| Noise Figure | ≤-8dB |
| Inter-modulation attenuation | (Po=13dBm) ≤-40dBm |
| Transmission Delay | ≤0.5μs |
| Ambient temperature | -10℃-50℃ |
| Power Supply | AC110-220V±10%/45-55Hz; |
| Size | 148mm×106mm×33mm |
| Reliability | To the GB6993-86 standard; |
| Electromagnetic Compatibility | To the ETS300 694-4 standard |
| Function | a) Power supply LED denote; |
| b) Export power LED denote; |
Package contents:
1 pcs booster
1 set power supply
1 pcs user manual
1 set installation screws
