| Uplink: | DCS1710-1785MHz; | Downlink: | DCS1805-1880MHz |
|---|---|---|---|
| DCS Uplink: | Gp≥65dB | DCS Downlink: | Gp≥70dB; |
| Output Power: | ≥23dBm | Pass Band Ripple: | DCS≤8dB; |
| High Light: | cellular signal booster,mobile signal amplifier |
||
1800MHz 23Dbm Mobile Phone Signal Booster/Indoor Home Using Mobile Repeater
Brief Description:
1800MHz Pico-Repeater is intended to strengthen the signal of 1800MHz mobile phone in the buildings. Ideal for use in areas where the 1800MHz signal is weak to cause Call dropout or Cant connection. The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator).
Features:
Applicable place:
It can be applied in Building rooms there have weak signal of mobile.
Specification:
| Frequency Range | (Uplink:DCS1710-1785MHz; Downlink:DCS1805-1880MHz); |
| Gain | (DCS Uplink)Gp≥65dB; (DCS Downlink)Gp≥70dB; |
| Output Power | ≥23dBm |
| Pass band ripple | DCS≤8dB; |
| Guard band rejection | DCS (BW-60DB) ≤104MHz; |
| DCS (BW-70dB)≤107MHz; | |
| I/O impedance | 50Ω/N Connector |
| I/O return loss | ≤-8dB |
| Noise figure | ≤-8dB |
| Inter-modulation attenuation(Po=13dBm) | ≤-40dBm |
| Transmission | ≤0.5μs |
| Ambient | -10℃-50℃ |
| Power Supply | AC110-220V±10%/45-55Hz; |
| Size | 148mm×106mm×33mm |
| Reliability | To the GB6993-86 standard; |
| Electromagnetic | To the ETS300 694-4 standard; |
| Function | a) Power supply LED denote |
| b) Export power LED denote |
Order Information :
1800MHz Pico-Repeater Model:TE1823: Cover-max 100-500 square meters;
Package contents:
1 pcs booster
1 set power supply
1 pcs user manual
1 set installation screws
