| Frequency Range: | TE-7023 (Uplink:703-748MHz; Downlink:758-803MHz) | Gain: | TE-7023(700MHz Uplink)Gp≥65dB; (700MHz Downlink)Gp≥70dB; |
|---|---|---|---|
| Output Power: | TE-7023 ≥23dBm | Pass Band Ripple: | 4G700MHz≤8dB |
| Guard Band Rejection: | 4G700MHz(BW-70dB）≤107MHz | Power Supply: | AC110-220V±10%/45-55Hz |
| Size: | 148mm×106mm×33mm | ||
| High Light: | cellular signal booster,mobile signal amplifier |
||
700MHz High Gain Cell Phone Signal Booster/100-500 Square Meters Mobile Phone Signal Repeater
Brief Description:
700MHz Pico-Repeater is intended to strengthen the signal of 700MHz mobile phone in the buildings. Ideal for use in areas where the 700MHz signal is weak to cause Call dropout or Cant connection.The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator).
Features:
Applicable place:
It can be applied in Building rooms there have weak signal of mobile.
Specification:
| Frequency Range |
TE-7023 (Uplink:703-748MHz; Downlink:758-803MHz) |
| Gain | TE-7023(700MHz Uplink)Gp≥65dB; (700MHz Downlink)Gp≥70dB; |
| Output Power | TE-7023 ≥23dBm |
| Pass band ripple | 4G700MHz≤8dB |
| Guard band rejection | 4G700MHz (BW-60DB) ≤104MHz |
| 4G700MHz(BW-70dB)≤107MHz | |
| I/O impedance | 50Ω/NConnector |
| I/O return loss | ≤-8dB |
| Noise figure | ≤-8dB |
| Inter-modulation attenuation(Po=13dBm) | ≤-40dBm |
| Transmission | ≤0.5μs |
| Ambient | -10℃-50℃ |
| Power Supply | AC110-220V±10%/45-55Hz |
| Size | 148mm×106mm×33mm |
| Reliability | To the GB6993-86 standard |
| Electromagnetic | To the ETS300 694-4 standard |
| Function | a) Power supply LED denote |
| b) Export power LED denote |
Order Information :
700MHz Pico-Repeater Model:TE-7023: Cover-max 100-500 square meters;
Package contents:
1 pcs booster
1 set power supply
1pcs user manual
1 set installation screws
