Product Details:
Payment & Shipping Terms:
|
| Power Supply: | AC110-220V±10%/45-55Hz; | Size: | 148mm×106mm×33mm; |
|---|---|---|---|
| Reliability: | To The GB6993-86 Standard; | Electromagnetic Compatibility: | To The ETS300 694-4 Standard |
| Function: | B) Export Power LED Denote | ||
| Highlight: | mobile network booster device,cellular signal booster |
||
2GGSM850MHzPCS1900MHz Mobile Phone Signal Amplifier/Dual Band Signal Amplifier
Brief Description:
GSM/PCS Dual band Signal Booster TE8019B is intended to strengthen
The signal of 850MHz/1900MHz mobile phone in the buildings. Ideal for use in areas where the 850MHz/1900MHzsignal is weak to cause Call dropout or Cant connection.The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator).
Features:
Applicable place:
It can be applied in Building rooms there have weak signal of mobile.
Specification:
| Frequency Range |
Uplink: GSM:824-849/PCS:1850-1910MHz; Downlink: GSM: 869-894/PCS:1930-1990MHz;
|
| gain(dB) | GSM Uplink:Gp≥65;GSM Downlink:Gp≥70;PCS Uplink: Gp≥65; PCS Downlink: Gp≥70; |
| Output power(dBm) | ≥23 |
| Gain adjustable range | MGC≥30dB |
| Pass band ripple | GSM≤4dB; PCS≤15dB; |
| Guard band rejection | GSM(BW-60dB)≤42MHz; (BW-70dB)≤45MHz; |
| PCS(BW-60dB)≤104MHz; (BW-70dB)≤107 MHz; | |
| I/O Impedance | 50Ω/N Connector; |
| I/O return loss | ≤-10dB |
| Noise Figure | ≤-8dB; |
| Inter-modulation attenuation(Po=13dBm) | ≤-40dBm; |
| Transmission Delay | ≤0.5μs |
| Ambient Temperature | -10℃-50℃ |
| Power Supply | AC110-220V±10%/45-55Hz; |
| Size | 148mm×106mm×33mm; |
| Reliability | To the GB6993-86 standard; |
| Electromagnetic compatibility | To the ETS300 694-4 standard |
| Function | a) Power supply LED denote |
| b) Export power LED denote |
Package contents:
1pcs AC90-264V,DC5/5A power supply adapter;
1pcs AC power cord (EU standard/US standard/UK standard/ SA standard/China standard etc);
1pcs Installation kit;
1pcs User manual;
